AT520L

Battery Voltage Meter,Battery Internal Resistance Meter

                          • Battery Internal Resistance Meter
                          • Four Colors VFD Display
                          • Vector Measurement, 3 Parameters Dispaly
                          • Comparator (sorting) Function): Build-in 30 sets comparators, HI/IN/LOW/GD/NG Display and Output
                          • Beep and Brightness can be Adjusted
                          • Four-terminal resistance measurement
                          • Internal,Manual,External and Remote Trig
                          • Keypad lock and data hold function
                          • Build-in RS232C and Handler,Optional GPIB Interface
 General Characteristics
 Parameter  AC resistance, DC voltage,θ
 Accuracy  Resistance:0.5%; Voltage:0.1%
 Measurement Range  Resistance:10μΩ~32Ω;Voltage:1mV~60VDC
 Max Reading  Resistance: 32,000, Voltage: 60,000
 Dimension  264mm (W)x107mm (H)x350mm (D)
 Weight  4kg
